Specification

Full Specification

116"

157"

231"

157 Inch - WDAIODVLED157-A

Resolution (px)

1280x960

Unit Size (mm)

3200x2400x31.4

Net Weight (Kg)*

155

Average Power Consumption (W)

825

*Excluding Mount

231 Inch - WDAIODVLED231-A

Resolution (px)

2048x1152

Unit Size (mm)

5120x2880x31.4

Net Weight (Kg)*

297.6

Average Power Consumption (W)

1584

*Excluding Mount

LED Display

Pixel Pitch (mm)

P2.5

LED Type

SMD2121

Pixel configuration

1R1G1B

Brightness (Calibrated)

2,200cd/m²

Refresh Rate

3840Hz

Contrast Ratio

6,500:1

Viewing Angle

170°

Processing

12 bit

Frame rate

60 fps

Maintenance

Front Service

Power

Input Voltage

AC220/110 ± 10%, 47~63Hz

Environmental

IP Rating

IP40

Operating Temperature

-10°C to 60°C

Operating Humidity

10% to 80%

Lifetime

100,000 hours

Computer - 116" and 157"

Media Formats

Video (MPG, AVI, MP4, RM, RMVB, TS), Audio (MP3, WMA), Image (JPG, GIF, BMP, PNG)

Media Resolution

1920x1080/1080x1920

Internal Memory

32GB

CPU

Quad-Core Cortex-A17@1.61GHz

GPU

Mali-T760 MP4 @600MHz

RAM

4GB DDR3

USB

USB2.0 HOST (x4)

LAN

10/100Mb/s Ethernet

Wi-Fi

802.11b/g/n

OS

Android 7.1

Graphic Engine

OpenGL ES 1.1/2.0/3.0/3.1, OpenCL 1.1, Renderscript, Direct3D 11.1

Computer - 231"

Media Formats

Video (MPG, AVI, MP4, RM, RMVB, TS), Audio (MP3, WMA), Image (JPG, GIF, BMP, PNG)

Media Resolution

3840x2160/2160x3840

Internal Memory

32GB

CPU

Rockchip RK3399 @1.8GHz

GPU

Mali-T860 MP4 @600MHz

RAM

4GB DDR3

USB

USB2.0 HOST (x2), USB3.0 HOST (x2)

LAN

10/100Mb/s Ethernet

Wi-Fi

802.11b/g/n/ac

OS

Android 10

Graphic Engine

OpenGL ES 1.1/2.0/3.0/3.1, OpenCL 1.1, Renderscript, Direct3D 11.1

Spec Sheet

DV-LED All-in-One Window Displays - Spec Sheet

Why Choose Our Commercial Display Solutions?

Lifetime Technical Support

From the moment you receive your product, throughout the duration of your warranty and even after your warranty has expired we are here to support you. If you require any assistance is setting up or using your product, or have any problems at all, we can provide free technical support via telephone and email.

On-site Support and Maintenance

If needed, we can provide an installation service for any of our products. We can also set up service-level agreements for larger projects that require maintenance contracts. *Additional charges may apply.

Extended Warranty

All of our commercial display products come with a 3 year commercial warranty as standard but if you want to extend this you can upgrade this to cover a 5 year period. *Additional charges may apply.

Training

As well as providing free remote CMS training sessions and webinars we can also visit you to deliver bespoke training for our software and hardware* Additional charges may apply.

Advanced Replacements

Should your display suffer from any kind of hardware failure during the warranty period we will send you an advanced replacement and arrange for your old display to be collected, free of charge. This ensures no downtime where you are without a screen.

Custom Product Testing & Configuration

If you need us to test third party software or a website, or configure your screen in a particular way before it is dispatched (e.g. in a particular orientation or network mode), we can do so to make your life easier.

3D Rendering

Want to know how a particular screen will look once installed? Send us a photo of the location and we will create a 3D rendering of any screen in situ to help you to visualise how amazing it will look.

Logistics Support

We hold more stock in our UK warehouse than any other manufacturer so we can help you meet tight deadlines. For last minute orders we can also offer special express or morning delivery options (additional charges may apply). We also carry out UK based quality control checks on every display before it leaves our warehouse.

Project Support

If you need to loan a sample unit to test we’d be more than happy to arrange this. We can also provide a rental service for temporary projects* Additional charges may apply.

Customisation

Your display can be customised to suit your requirements by adding your logo or printed graphics or even tailoring the colour of a display. We can also carry out hardware modifications to existing products or manufacture bespoke solutions for special projects. *Additional charges may apply

Extras

As well as being able to provide accessories and add-ons, such as extra remote controls, NUC PCs and video wall controllers, we can also supply custom made flight cases which are great if a display needs to be moved safely from place to place. *Additional charges may apply
