2,200cd/m² Window Displays

Engineered for use in window displays, our High Brightness Indoor Direct View LED solution brings all the same great features as our standard Indoor DV-LED but with a brightness of 2,200cd/m² is optimised to deliver outstanding brightness even in direct sunlight.

Captivating Image Quality

State-of-the-art SMD Direct View LED technology and an ultra-high 6,500:1 contrast ratio guarantee that these video walls deliver stunning image quality. Experience vivid colours, true black and crystal clarity across the seamless display. Plus, advanced video processing technology ensures colours are accurate and lifelike without any distortion.

Complete Package Solution

This all-in-one package contains everything needed to get your display up and running, including the LED modules and mounting bracket. For larger DV-LED video walls an aluminium screen edge can also be made to order at no additional cost, protecting the display and improving the overall aesthetic.

Easy Installation and Maintenance

Thanks to their lightweight design, magnetic modules, positioning pins and simple cabinet structure, these displays are incredibly easy to install. Made from robust aluminium, the cabinets are warp-resistant, ensuring perfect alignment for a flawless finish. After installation, they can be serviced from the front of the display by quickly and efficiently removing the DV-LED modules for ultimate ease of maintenance.

End-to-End Project Management

As every Direct View LED project is unique, they each come with their own challenges. We are here to advise and support you every step of the way. From designing bespoke displays to ensuring hassle-free installation and even providing maintenance, we can deliver full end-to-end project management where required.

Complete Quality Control

From production through to installation, our video walls undergo multiple rounds of strict quality control to ensure long-lasting reliability. In addition, quality calibration guarantees consistent image quality across the whole display.

Modular Video Walls

Thanks to their modular design, these versatile displays are not constrained by standard aspect ratios. Stand out from the crowd by sculpting seamless large-scale video walls to fill spaces of any shape and size in any location. The unique cabinet size gives ultimate flexibility by ensuring a 16:9 aspect ratio is also possible.

UK Stock Held

Our fully-stocked UK warehouse means we can fulfil projects with a rapid turnaround time if required. From initial enquiry to finished installation, by holding extensive stock in the UK we can deliver results without long delays.

Gallery

Specification

Full Specification

P1.8

Pixel Pitch (mm)

1.8

LED Type

SMD1515

Module Resolution (px)

172x86

Cabinet Resolution (px)

344x258

Refresh rate

2880Hz

Cabinet Current

≤0.45A

Average Power Consumption (Per Cabinet)

35W

Max Power Consumption (Per Cabinet)

100W

Standby Power Consumption (Per Cabinet)

15W

P2.5

Pixel Pitch (mm)

2.5

LED Type

SMD2121

Module Resolution (px)

128x64

Cabinet Resolution (px)

256x192

Refresh rate

3840Hz

Cabinet Current

≤0.45A

Average Power Consumption (Per Cabinet)

33W

Max Power Consumption (Per Cabinet)

95W

Standby Power Consumption (Per Cabinet)

15W

P3.1

Pixel Pitch (mm)

3.17

Module Resolution (px)

48x108

Cabinet Resolution (px) - Option A

348x108

Cabinet Resolution (px) - Option B

261x108

Cabinet Resolution (px) - Option C

174x108

P3.9

Pixel Pitch (mm)

3.9

Module Resolution (px)

40x90

Cabinet Resolution (px) - Option A

320x90

Cabinet Resolution (px) - Option B

240x90

Small Cabinet Resolution (px) - 16:9

160x90

P2.5

Pixel Pitch (mm)

2.5

LED Type

SMD2121

Module Resolution (px)

128x64

Cabinet Resolution (px)

256x192

Refresh rate

3840Hz

Cabinet Current

≤0.45A

Average Power Consumption (Per Cabinet)

33W

Max Power Consumption (Per Cabinet)

95W

Standby Power Consumption (Per Cabinet)

15W

LED

Brightness (Calibrated)

2,200cd/m²

Contrast Ratio

6,500:1

Viewing angle

170°

Processing

12 bit

Frame Rate

60 FPS

Maintenance

Front service

Cabinet

Module Size (mm)

320x160x14.5

Cabinet Size (mm)

640x480x31.4

Net weight (Kg)

6.8

Power

Input Voltage

240V AC

Environmental

Operating Temperature

-10ºC to +30ºC

Operating Humidity

10% to 65%

Lifetime

100,000 hours

Videos

Case Studies

Digital Signage Case Study – International Footwear Brand

International Footwear Brand (IFB) is an American fashion company founded in 1978 primarily known for its sheepskin boots and also specialise in other footwear, accessories and home textiles. Renowned for their distinctive premium and comfortable footwear the brand is synonymous with high quality products. Founded in the USA, the brand has several successful stores in the UK with two in London’s premiere shopping districts.

For their London stores the brand works with one of our partners who are an award-winning design studio. In December of 2021 IFB approached their longstanding design partner to help revamp the front window displays of their Piccadilly and Westfield stores . . .

Continue Reading

Download PDF

Downloads

Spec Sheet

High Brightness Indoor Direct View LED Solutions - Spec Sheet

Technical Drawings

High Brightness Indoor Direct View LED Solutions - Technical Drawing

Installation Guide

Indoor DV-LED - Installation Guide

Indoor DV-LED - With Protective Edging - Installation Guide

Resources

Indoor DV-LED - 16:9 Aspect Ratio Guide

Why Choose Our Commercial Display Solutions?

Lifetime Technical Support

From the moment you receive your product, throughout the duration of your warranty and even after your warranty has expired we are here to support you. If you require any assistance is setting up or using your product, or have any problems at all, we can provide free technical support via telephone and email.

On-site Support and Maintenance

If needed, we can provide an installation service for any of our products. We can also set up service-level agreements for larger projects that require maintenance contracts. *Additional charges may apply.

Extended Warranty

All of our commercial display products come with a 3 year commercial warranty as standard but if you want to extend this you can upgrade this to cover a 5 year period. *Additional charges may apply.

Training

As well as providing free remote CMS training sessions and webinars we can also visit you to deliver bespoke training for our software and hardware* Additional charges may apply.

Advanced Replacements

Should your display suffer from any kind of hardware failure during the warranty period we will send you an advanced replacement and arrange for your old display to be collected, free of charge. This ensures no downtime where you are without a screen.

Custom Product Testing & Configuration

If you need us to test third party software or a website, or configure your screen in a particular way before it is dispatched (e.g. in a particular orientation or network mode), we can do so to make your life easier.

3D Rendering

Want to know how a particular screen will look once installed? Send us a photo of the location and we will create a 3D rendering of any screen in situ to help you to visualise how amazing it will look.

Logistics Support

We hold more stock in our UK warehouse than any other manufacturer so we can help you meet tight deadlines. For last minute orders we can also offer special express or morning delivery options (additional charges may apply). We also carry out UK based quality control checks on every display before it leaves our warehouse.

Project Support

If you need to loan a sample unit to test we’d be more than happy to arrange this. We can also provide a rental service for temporary projects* Additional charges may apply.

Customisation

Your display can be customised to suit your requirements by adding your logo or printed graphics or even tailoring the colour of a display. We can also carry out hardware modifications to existing products or manufacture bespoke solutions for special projects. *Additional charges may apply

Extras

As well as being able to provide accessories and add-ons, such as extra remote controls, NUC PCs and video wall controllers, we can also supply custom made flight cases which are great if a display needs to be moved safely from place to place. *Additional charges may apply
